No

 Item

 Specification

 1

 Nominal Voltage

 DC 51.2V

 2

 Nominal Capacity

100Ah

 3

Capacity@0.2C

 300min

 4

 Energy

5,120Wh

 5

Resistance

 ≤30mΩ

 6

 Efficiency

 99%

 7

 Self discharge

 ≤3.5% Per month

 8

 Maximum Module in parallel

 15

 9

 Maximum continuous discharging current

 100A

 10

 Peak discharging current

 150A≤3s

 11

 BMS discharge current cut-off

 130A±20A

 12

 Recommend Low voltage disconnect

 42V

 13

Discharge Temperature

 -20 to 60 ℃

 14

 Charge Temperature

 0 to 45 ℃

 15

 Low Temperature cut-off charge

 0 ℃（Customized)

 16

 High Temperature cut-off charge

 (54℃（Customized)

17

Dimensions

436.8(486.8) X 453(435.5) X 200

          18

 Weight

50.25 kg

          19

 Terminal Type

Connector

         20

 Case material

 Steel

         21

 Enclosure Protection

IP20

         22

 Chemistry

Lifepo4

         23

 Recommend charge current

50A

         24

 Maximum charge current

50A

         25

 Recommend charge Voltage

 54.5V

         26

 Battery Pack Discharging Low Voltage

 41.6V

         27

 Communication

 RS485/CAN

         28

 Warranty

 5 Years
