Products

AIO 600



internal accessories

-.  LifePO4 Battery 60A

-.  Cigar charging 7.5A

-.  Pure sine wave 600W



composition

 -. User Manual (Quality Warranty / 2 Year Quality Warranty Period)

-. Cigar charging line -.10A AC charger

4134357baaed363dcc8fd1f6de687a02_1718330976_0458.JPG4134357baaed363dcc8fd1f6de687a02_1718331007_8083.JPG
















※ Lithium iron phosphate battery features

01. The most economical and efficient battery

Lithium iron phosphate batteries have a lifespan about 10 times longer than lead-acid batteries of the same capacity and have about twice the energy density per weight.

In addition, there is no memory effect, so there is no loss of capacity, and rapid charging and low natural discharge rate allow for long-term use, making it an efficient and economical battery used in various fields.




02. High safety and durability

It is the safest against fire and explosion among existing batteries and does not emit flammable gases.

Its durability is excellent as there is no loss of weight even in hot summers and extreme winters (-20℃ to 60℃).



03. Eco-friendly, non-toxic future battery

Lithium iron phosphate batteries are safe as they are made from eco-friendly raw materials that do not contain high concentrations of sulfuric acid or potassium hydroxide.

In addition, there is no risk of hydrogen gas leaking when overcharging, and performance does not drop drastically in high or low temperature environments, so there is a low risk of explosion.



 MODEL

AIO 600

 Nominal  Voltage

 12.8V

 Capacity

60Ah 768Wh

Charger Input

Max. 14.6V 30A (recommended current Max. 20A)

Cigar Charger Input

DC 11V~15V (Max.10A)

Cigar Charging Current

Max. 7A

AC Wave form

120V or 220V 50/60Hz 2Port(Sum. Max. 600W )

AC Output power

Pure sine wave inverter



 DC Output

XT-90 male ( Max. 90A 1Port ) (recommended current Max. 70A)

QC 3.0 (USB-A 1Port) ,PD (USB-C 5V3A, 9V2A, 12V1.5A)

MAX. 1.5A(18W) 1Port

Cigar 12V Max. 10A (120W) 1Port

DC jack (5.5 * 2.1 ) 60W 1Port

 Safety Protection

 BMS

 Case

Alluminum

 Recommended Charging TEMP

 0℃ ~ 45℃

 Recommended Discharging TEMP

-20℃ ~ 60℃

 Weight

About 7.60kg

 Sie(L X W X H)

463 X 114 X 221

 L : length /  W : Width / H : height
